TROUBLESHOOTING AND HYDRAULIC DIAGRAM| PAGE 21
7. TROUBLE SHOOTING
Due to the simplicity of the system, breakdowns are practically none. However, in
the event of any failure, please contact with our after-sales service.
8. HYDRAULIC DIAGRAM
Cylinder
Valve
Tube
Pressure relay
Valve
Valve
1 mm
Filter Filter
Oil tank
Valve
Valve
Gear groupDC engine
6.3 MOBILE EQUIPMENT
Maintenance of mobile equipment (ref. Manual of head, inertia coupling and
shaft of the mobile kit)
