Hirschmann MSM20 User Manual

Installation MSP30/32/40/42 and MSM20/22/24/40/42/46/50
Release 12 06/2018
33
 PoE-capable media modules MSM22, MSM42 and MSM46
The MSM22, MSM42 and MSM46 PoE media modules support Power
over Ethernet (PoE) according to IEEE 802.3af and Power over Ethernet
Plus (PoE+) according to IEEE 802.3at.
1 Port 1 (Twisted Pair)
2 Port 2 (Twisted Pair)
3 Port 3 (Twisted Pair)
4 Port 4 (Twisted Pair)
Table 16: MSM22-T5T5T5T5...
1 Port 1 (Twisted Pair)
2 Port 2 (Twisted Pair)
3 Port 3 (Twisted Pair)
4 Port 4 (Twisted Pair)
Table 17: MSM42-T1T1T1T1...
1 Port 1 (Twisted Pair)
2 Port 2 (Twisted Pair)
3 Port 3 (Twisted Pair)
4 Port 4 (Twisted Pair)
5 3-pin terminal block for the PoE supply voltage
Table 18: MSM46-T1T1T1T1...
1
2
3
4
P
++
1
2
3
4
P
+
+
1
2
3
4
5
P
+
+
