Hirschmann OCTOPUS OS3 User Manual

Installation OCTOPUS OS3
Release 01 02/2019
13
5 Data rate 4 10
a
/100/1000 Mbit/s
6 Hardware type 0 Standard
7 (hyphen) -
8 ... 9 Number:
PoE ports
PoE(+) ports
00 0 ×
10 ... 11 Number:
10
a
/100 Mbit/s PoE/
PoE+ ports
00 0 × 10
a
/100 Mbit/s PoE/PoE+ ports
12 ... 13 Number:
10
a
/100/1000 Mbit/s
PoE/PoE+ ports
00 0 × 10
a
/100/1000 Mbit/s PoE/PoE+ ports
14 ... 15 Number:
10
a
/100 Mbit/s ports
00 0 × 10
a
/100 Mbit/s ports
16 ... 17 Number:
10
a
/100/1000 Mbit/s
ports
24 24 × 10
a
/100/1000 Mbit/s ports
18 ... 19 Number:
Ports >1000 Mbit/s
00 0 × 10000 Mbit/s ports
20 ... 21 First uplink port pair T6 Standard
22 ... 23 Second uplink port
pair
T6 Standard
24 (hyphen) -
25 Temperature range T Extended -40 °F ... +158 °F (-
40 °C ... +70 °C)
26 ... 27 Supply voltage N9 Rated voltage 72 V DC ... 110 V DC
Rated voltage range 50.4 V DC ... 138 V DC
Connection type 5-pin M12 connector
28 ... 29 Certificates and
declarations
S9 Z9 + EN 50121-4 + EN 50155
30 ... 31 Software packages MR Unicast + Multicast Routing
32 ... 33 Customer-specific
version
HH Hirschmann standard
34 Hardware
configuration
S Standard
35 Software configuration E Entry (Hirschmann Standard)
36 ... 37 Software level 3A HiOS Layer 3 Advanced
38 ... 42 Software version 07.5. Software version 07.5.
XX.X Current software version
43 ... 44 Maintenance version XX Current maintenance version
45 ... 47 Place of manufacture -NT Manufactured in Germany
a. Exclusively for twisted pair connections.
Item Characteristic Characteri
stic value
Description
Table 1: Device name and product code
