Installation OCTOPUS OS3
Release 01 02/2019
7.3 Signal contact
7.4 Power consumption/power output
Signal contact
Connection type 5-pin, “A”-coded M12 plug
Tightening torque 4.5 lb-in (0.51 Nm)
Nominal value I
max
=1A at U
max
=30VAC
I
max
=1A at U
max
=60VDC
Table 7: Signal contact
Device name Maximum power consumption Maximum power output
OCTOPUS 24GE-HV-
Trainrouter
32 W 110 Btu (IT)/h
Table 8: Power consumption/power output
