7
5. Technical data
General data
Operating voltage DC 18 to 32 V safety extra-low voltage (SELV) (redundant inputs decoupled)
Current consumption 500 mA (RS1) and 1.2A (RM1) respectively maximum, at 24 VDC
Overload current protection at input non-changeable thermal fuse
Dimensions W x H x D 210 mm x 125 mm x 85 mm (RS1) and 434 mm x 44 mm x 279 mm (RM1) respectively
8,3 in x 4,9 in x 3,3 in (RS1) and 17,1 in x 1,7 in x 11 in (RM1) respectively
Mass RS1 1,36 kg (3,0 lb), RM1 3,5 kg (7,7 lb)
Ambient temperature 0 ºC to + 60 ºC (RS1) and 0 ºC to + 40 ºC (RM1) respectively
Storage temperature - 40 ºC to + 80 ºC
Humidity 10% to 90% (not-condensing)
Protection class IP 20 (RS1), IP 30 (RM1)
Radio interference level EN 55022 Class B
Interference immunity EN 50082-2
Network size
TP port 10BASE-T
Length of a twisted pair segment 100 m (328 ft) maximum
TP port 100BASE-TX (ETSXM-01TP(FE), RS1-TX/TX and RS1-TX/FX)
Length of a twisted pair segment 100 m (328 ft) maximum
F/O port 100BASE-FX (ETSXM-01MM(FE), RS1-FX/FX und RS1-TX/FX)
According to IEEE 802.3u 100BASE-FX
System attenuation
50/125 µm fiber 8 dB
62,5/125 µm fiber 11 dB
10/125 µm fiber 11 dB
Wave length 1300 nm
F/O line length (example)
50/125 µm fiber 3000 m (9843 ft) maximum (data of fiber: 1,6 dB/km, 500 Mhz
*
km)
62,5/125 µm fiber 3000 m (9843 ft) maximum (data of fiber: 2,6 dB/km, 500 Mhz
*
km)
10/125 µm fiber 40 km (131.234 ft) maximum (data of fiber: 0,2 dB/km)
Scope of delivery
Rail Switch RS1 incl.
terminal block for supply voltage
description and operating instructions
Redundancy Manager RM1 incl.
terminal block for supply voltage
description and operating instructions
4 rubber feet (RM1)
1 pair mounting brackets (RM1)
Order number
Rail Switch RS1-FX/FX 943 606-031
Rail Switch RS1-TX/TX 943 606-001
Rail Switch RS1-TX/FX 943 606-032
Rail Switch RS1-TX/FX-SM 943 606-033
Redundancy Manager RM1 943 632-001
Accessories
Ethernet manual 943 320-011
100BASE-X-Module
ETSXM01TP(FE) 943 567-001
ETSXM01MM(FE) 943568-001
