Hirschmann RS20 series User Manual

Installation RS20/22/30/32/40
Release 05 12/2015
65
Power supply
RS22-..., RS32-...
Nominal voltage AC 48 V
Max. voltage range AC 47 V ... 52 V
(incl. max. tolerances)
Connection type 6-pin terminal block with snap lock
Power loss buffer > 10 ms
Back-up fuse Nominal rating:
Characteristic:
3.5 A
slow blow
Peak inrush current < 14 A
PoE power unit
RPS90/48V HV
Nominal voltage AC 110 V ... 230 V, 50 Hz ... 60 Hz
Voltage range AC 90 V ... 265 V, 47 Hz ... 63 Hz
(incl. max. tolerances)
Power consumption at 110 V AC
Power consumption at 230 V AC
1.00 A
0.50 A
Nominal voltage DC 60 - 250 V
Voltage range DC 48 V ... 320 V (incl. max. tolerances)
Current consumption at 60 V DC
Current consumption at 250 V DC
1.70 A
0.39 A
Connection type 3-pin terminal block
Output voltage 48 V ... 54 V DC (variable, default
value: 48 V DC)
Power output At up to +60 °C: 90 W
At +60 °C to +70 °C: 60 W
Power loss buffer > 10 ms
Back-up fuse Nominal rating:
Characteristic:
6.3 A
slow blow
Peak inrush current < 15 A
PoE power unit
RPS90/48V LV
Nominal voltage DC 24 V ... 48 V
Voltage range DC 18 V ... 60 V (incl. max. tolerances)
Current consumption at 24 V DC
Current consumption at 48 V DC
4.20 A
2.10 A
Connection type 2-pin terminal block
Output voltage 48 V ... 54 V DC (variable, default
value: 48 V DC)
Power output At up to +60 °C: 90 W
At +60 °C to +70 °C: 60 W
Power loss buffer > 10 ms
Back-up fuse Nominal rating:
Characteristic:
10 A
slow blow
Peak inrush current < 15 A
Overload current
protection at input
Non-replaceable fuse
Insulation voltage
between supply
voltage connections
and housing
800 V DC
Protective elements limit the
insulation voltage to 90 V DC (1 mA)
“FAULT”
signal contact
Switching current max. 1 A, SELV
Switching voltage max. 60 V DC or max. 30 V AC,
SELV
