Hirschmann RS40 series User Manual

68
Installation RS20/22/30/32/40
Release 05 12/2015
Figure 23: Dimensions of device variants
- RS20-16... , RS20-17... and RS20-24... with operating temperature
characteristic value S, T and E
- RS30-16... and RS30-24... with operating temperature
characteristic value S, T and E
- RS40-09... with operating temperature characteristic value T and E
Figure 24: Dimensions of device variants RS22.../RS32... with 8 to 10 ports with
operating temperature characteristic value S, T and E
3,5
0.14
mm
inch
106 14
130
5.12
0.554.17
110
4.33
90
115
12
9
137
4.533.55 0.47
5.39
0.36
