Installation RS20/22/30/32/40
Release
05
12/2015
75
Order numbers/product description
The order numbers correspond to the product codes of the devices.
See “Combination options of the device variants
RS20/RS30/RS22/RS32” on page 23.
See “Combination options for the RS40 device variants” on page 26.
Accessories
Note that products recommended as accessories may have different
characteristics to those of the device, which may limit the application
range of the overall system. For example, if you add an accessory with IP
20 to a device with IP 65, the IP of the overall system is reduced to 20.
Gigabit Ethernet SFP transceiver Order number
M-SFP-TX/RJ45 943 977-001
The following operating conditions apply to twisted pair transceivers:
Usable with:
- HiOS as of software version 03.0.00
- Classic Switch software, as of software version 04.1.00.
- HiSecOS as of software version 01.2.00
Do not use with the following devices:
- SPIDER II
- MSP/MSM
- EES
Longer RSTP switching times and link loss detection times compared to twisted pair ports
provided by the device directly.
Not applicable for combo and Fast Ethernet ports.
Only support of the autonegotiation mode including autocrossing.
M-SFP-SX/LC 943 014-001
M-SFP-SX/LC EEC 943 896-001
M-SFP-MX/LC EEC 942 108-001
M-SFP-LX/LC 943 015-001
M-SFP-LX/LC EEC 943 897-001
M-SFP-LX+/LC 942 023-001
M-SFP-LX+/ LC EEC 942 024-001
M-SFP-LH/LC 943 042-001
M-SFP-LH/LC EEC 943 898-001
M-SFP-LH+/LC 943 049-001
Bidirectional Gigabit Ethernet SFP transceiver Order number
M-SFP-BIDI Type A LX/LC EEC 943 974-001
M-SFP-BIDI Type B LX/LC EEC 943 974-002
M-SFP-BIDI Type A LH/LC EEC 943 975-001
M-SFP-BIDI Type B LH/LC EEC 943 975-002
M-SFP-BIDI Bundle LX/LC EEC (type A + B) 943 974-101
M-SFP-BIDI Bundle LH/LC EEC (type A + B) 943 975-101
