76
Installation RS20/22/30/32/40
Release
05
12/2015
Fast Ethernet SFP transceiver Order number
M-FAST SFP-TX/RJ45 942 098-001
M-FAST SFP-TX/RJ45 EEC 942 098-002
The following operating conditions apply to twisted pair transceivers:
Usable with:
- HiOS as of software version 03.0.00
- for PRP ports on RSP devices, as of software version 02.0.01
- for PRP ports on EES devices, as of software version 02.0.02
- Classic switch software as of software version 08.0.00
- HiSecOS ab Software-Version 01.2.00
Longer RSTP switching times and link loss detection times compared to twisted pair ports
provided by the device directly.
Not applicable for combo ports.
Not applicable for ports which support only Gigabit Ethernet.
To set autocrossing manually is currently not possible.
M-FAST SFP-MM/LC 943 865-001
M-FAST SFP-MM/LC EEC 943 945-001
M-FAST SFP-SM/LC 943 866-001
M-FAST SFP-SM/LC EEC 943 946-001
M-FAST SFP-SM+/LC 943 867-001
M-FAST SFP-SM+/LC EEC 943 947-001
M-FAST SFP-LH/LC 943 868-001
M-FAST SFP-LH/LC EEC 943 948-001
Special accessories for the device variants RS22/RS32 Order number
Wall mounting plate in DIN rail design, width 4.72 in. (120 mm) 943 971-001
Wall mounting plate for DIN rail mounting, width 3.54 in. (90 mm) 943 971-002
RPS 90/48V HV (high-voltage) PoE power unit 943 979-001
RPS 90/48V HV (high-voltage) PoE power unit with conformal coating 943 979-101
RPS 90/48V LV (low-voltage) PoE power unit 943 980-001
RPS 90/48V LV (low-voltage) PoE power unit with conformal coating 943 980-101
Other accessories Order number
AutoConfiguration Adapter ACA21-USB (EEC) 943 271-003
Terminal cable 943 301-001
6-pin terminal block (50 pcs.) 943 845-006
Rail Power Supply RPS 30 943 662-003
Rail Power Supply RPS 80 EEC 943 662-080
Rail Power Supply RPS 120 EEC (CC) 943 662-121
Industrial HiVision Network Management Software 943 156-xxx
OPC server software HiOPC 943 055-001
