Redundancy
RM Web L2B
Release
5.3
05/2012
6.1
Ring Redundancy
85
Receive Ring information.
Delete the Ring Redundancy.
Note: Only one Ring Redundancy method can be enabled on one device at
any one time. When changing to another Ring Redundancy method,
deactivate the function for the time being.
Parameter Meaning
Version Select the Ring Redundancy version you want to use:
HIPER-Ring
MRP
Default setting is HIPER-Ring
Ring port No. In a ring, every device has 2 neighbors. Define 2 ports as ring ports to which the
neighboring devices are connected.
Module Module identifier of the ports used as ring ports
Port Port identifier of the ports used as ring ports
Operation Value depends on the Ring Redundancy version used. Described in the
following sections for the corresponding Ring Redundancy version.
Table 20: Ring Redundancy basic configuration
