Redundancy
RM Web L2B
Release
5.3
05/2012
6.2
Rapid Spanning Tree
97
Note: The parameters Forward Delay and Max Age have the following
relationship:
Forward Delay ≥ (Max Age/2) + 1
If you enter values that violate this rule, the device will replace these values
by the last valid values or the default values.
Bridge ID
(read only)
The local Bridge ID, made up of the local
priority and its own MAC address.
The format is
ppppp / mm mm mm mm mm mm,
with: ppppp: priority (decimal) and
mm: the respective byte of the MAC
address (hexadecimal).
Topology
Changes
This field displays the number of changes
since RSTP started.
Time since
last change
This field displays the time that has
elapsed since the last network
reconfiguration.
Information This frame shows whether there is a
configuration conflict.
In this case, the device with the MAC
address displayed is located outside the
MRP-Ring. The priority displayed for this
device is better (numerically smaller) than
the priority of the root bridge in the MRP-
Ring.
To resolve this conflict, set the device
displayed to a worse priority (numerically
greater) than the priority of the root bridge
in the MRP-Ring.
Parameter Meaning Possible
Values
Default Setting
Table 25: Global Spanning Tree settings, basic function
