Hirschmann SPIDER 3TX-TAP User Manual

Hirschmann Automation and Control GmbH
Stuttgarter Straße 45-51
D-72654 Neckartenzlingen
Germany
Tel.: ++49 / 1805 / 14-1538
Fax: ++49 / 7127 / 14-1551
E-Mail: hac-support@hirschmann.de
Internet: http://www.hirschmann.com
Printed in Germany
Subject to alterations
According to IEEE 802.3u 100BASE-FX
System attenuation
50/125 µm fiber (multimode MM) 0 to 8 dB
62,5/125 µm fiber (multimode MM) 0 to 11 dB
9/125 µm fiber (singlemode) 0 to 16 dB (SPIDER …TX/1FX-SM …)
Wave length (SM) 1300 nm
F/O line length (example)
50/125 µm fiber (multimode MM) 5 km approx. (data of fiber: 1.0 dB/km, 800 MHz
*
km)
62,5/125 µm fiber (multimode MM) 4 km approx. (data of fiber: 1.0 dB/km, 500 MHz
*
km)
9/125 µm fiber (singlemode SM) 30 km approx. (data of fiber: 1300 nm, 0.4 dB/km) (SPIDER …TX/1FX-SM …)
Interfaces
SPIDER 1TX/1FX, SPIDER 1TX/1FX EEC 1 TP/TX port RJ45 socket, 10/100 MBit/s
1 FX port Duplex SC connection, 100 MBit/s multimode MM
SPIDER 1TX/1FX-SM
, SPIDER 1TX/1FX-SM EEC 1 TP/TX port RJ45 socket, 10/100 MBit/s
1 FX port Duplex SC connection, 100 MBit/s singlemode SM
SPIDER 4TX/1FX, SPIDER 4TX/1FX EEC 4 TP/TX ports RJ45 sockets, 10/100 MBit/s
1 FX port Duplex SC connection, 100 MBit/s multimode MM
SPIDER 4TX/1FX-ST EEC 4 TP/TX ports RJ45 sockets, 10/100 MBit/s
1 FX port ST connector, 100 MBit/s multimode / MM
SPIDER 4TX/1FX-SM EEC 4 TP/TX ports RJ45 sockets, 10/100 MBit/s
1 FX port Duplex SC connection, 100 MBit/s singlemode SM
SPIDER 3TX-TAP 3 TP/TX ports RJ45 sockets, 10/100 MBit/s
SPIDER 5TX, SPIDER 5TX EEC 5 TP/TX ports RJ45 sockets, 10/100 MBit/s
SPIDER 8TX, SPIDER 8TX EEC 8 TP/TX ports RJ45 sockets, 10/100 MBit/s
Displays
Equipment status 1 x green LED P – power, supply voltage present
Port status
SPIDER 1TX/1FX... 2 x green LEDs DA/STAT – data, link status
1 x yellow LEDs 10/100 – data rate (TP port)
SPIDER 4TX/1FX... 5 x green LEDs DA/STAT – data, link status
4 x yellow LEDs 10/100 – data rate (TP ports)
SPIDER 3TX-TAP 3 x green LEDs DA/STAT – data, link status
3 x yellow LEDs 10/100 – data rate
SPIDER 5TX, SPIDER 5TX EEC 5 x green LEDs DA/STAT – data, link status
5 x yellow LEDs 10/100 – data rate
SPIDER 8TX, SPIDER 8TX EEC 8 x green LEDs DA/STAT – data, link status
8 x yellow LEDs 10/100 – data rate
Scope of delivery
Rail Switch SPIDER incl. terminal block for supply voltage
description and operating instructions
Order number
Rail Switch SPIDER 3TX-TAP 943 899-001
Rail Switch SPIDER 5TX 943 824-002
Rail Switch SPIDER 5TX EEC 943 824-102
Rail Switch SPIDER 8TX 943 376-001
Rail Switch SPIDER 8TX EEC 943 376-201
Rail Switch SPIDER 1TX/1FX 943 890-001
Rail Switch SPIDER 1TX/1FX EEC 943 927-001
Rail Switch SPIDER 1TX/1FX-SM 943 891-001
Rail Switch SPIDER 1TX/1FX-SM EEC 943 928-001
Rail Switch SPIDER 4TX/1FX 943 221-001
Rail Switch SPIDER 4TX/1FX EEC 943 221-101
Rail Switch SPIDER 4TX/1FX-ST EEC 943 914-001
Rail Switch SPIDER 4TX/1FX-SM EEC 943 880-001
Accessories
ETHERNET manual 943 320-011
Manual
Basics Industrial ETHERNET and TCP/IP 280 720-834
Rail Power Supply RPS 30 943 662-003
Rail Power Supply RPS 60 943 662-001
Rail Power Supply RPS 120 943 662-011

Hirschmann SPIDER 3TX-TAP Specifications

General

Brand	Hirschmann
Model	SPIDER 3TX-TAP
Category	Switch
Language	English
