3
Installing the Stand or Wall Mount Bracket
For
65"/75"
Attention
: According to the size of the TV supporting surface, you can select one of
the base stand installation patterns, as shown in the figure.
Base Stand
Base Stand
Base Stand
Base Stand
Screws
：
M5×16(65")
M5×12(75")
Screws
：
M5×16(65")
M5×12(75")
Screws
：
M5×16(65")
M5×12(75")
Screws
：
M5×16(65")
M5×12(75")
