6
TV Rear
NOTES
Check the jacks for position and type before making any connections.
Loose connections can result in image or color problems. Make sure
that all connections are tight and secure.
The TV may not be compatible with all external devices. To check
compatibility, please refer to the user manual of external device.
Do not connect external equipment while TV's power cord is plugged
in. It may cause electric shock.
Service jack is not available for you to connect an external device. It
can only be used by our factory for testing
purposes.
TV Rear
USB 2
DC 5V 0.5A(MAX)
HDMI 3
(4K@60Hz)
SERVICE
ANT
HDMI 2(
4K@60Hz
)
(eARC/ARC)
AV IN
USB 1
DC 5V 1A(MAX)
HDMI 1
(4K@60Hz)
AC INPUT
LAN
DIGITAL
AUDIO OUT
To Next Page
