Hisense HV643D60UK - User Manual

Hisense HV643D60UK
34 pages
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
Loading...
EN
User manual
Dishwasher
HV643D60UK

Questions and Answers

  • U
    umartinezSep 12, 2025
    What causes sticky white/blue film on dishes in Hisense Dishwasher?
    • L
      Leslie ReynoldsSep 12, 2025
      A sticky white or blue film on dishes from your Hisense Dishwasher is caused by a rinse aid dosage setting that is too high. Reduce the dosage. If you have very soft water, you may want to dilute the rinse aid 50:50 with water.
  • S
    Sandy CordovaAug 25, 2025
    Why are the dishes not clean in my Hisense HV643D60UK?
    • A
      Alexandria TorresAug 25, 2025
      The dishes might not be clean due to several reasons: - The spray arms may be blocked by dishes. Check and ensure they can rotate freely. - The spray arm holes or bearings may be blocked. Clean the spray arms. - The selected dishwashing program may be unsuitable. Select a program with a high temperature to dissolve grease, such as Intensive 70°. - The detergent dosage may be incorrect. Adjust the dosage according to water hardness. - The detergent may be old. Use fresh detergent and avoid large packages.
  • D
    Deanna CarrAug 26, 2025
    What to do if water remains in my Hisense Dishwasher?
    • C
      Christine HernandezAug 26, 2025
      If water remains in your Hisense Dishwasher: - The filter may be clogged. Clean the filter. - The filter may not be fitted correctly. Ensure it is correctly fitted. - There may be debris in the drainage pump. Clean the drainage pump. - The drainage pump stop may be missing. Check that the yellow drainage pump stop is in place. - There may be a kink in the drainage hose. Ensure the hose is free from kinks and sharp bends. - The drainage hose may be blocked. Disconnect the drainage hose and check for blockages, ensuring the connection has an inner diameter of at least 14 mm.
  • J
    joel14Aug 27, 2025
    How to fix dishes not dry enough in Hisense HV643D60UK Dishwasher?
    • A
      Anna AllenAug 27, 2025
      To improve drying in your Hisense Dishwasher: - Activate the Auto Dry setting. - Fully load the dishwasher. - Top up with rinse aid or increase the rinse aid dosage setting. - If the TAB setting is activated and you're using all-in-one detergent with insufficient drying effect, switch to separate detergents or deactivate the TAB setting and top up with salt and separate rinse aid.
  • P
    Patricia GentryAug 29, 2025
    How to fix spots on stainless steel or silver in Hisense Dishwasher?
    • D
      dustin40Aug 29, 2025
      To fix spots on stainless steel or silver in your Hisense Dishwasher: - Rinse off foodstuff like mustard, mayonnaise, lemon, vinegar, salt and dressings from dishes if not starting the dishwasher immediately. Consider using 1h 65° with the Speed wash option. - Separate dishes made from different metals, such as silver, stainless steel, and aluminum. - Adjust the rinse aid dosage setting. - If the TAB setting is activated and you're using all-in-one detergent with insufficient drying effect, switch to separate detergents or deactivate the TAB setting and top up with salt and separate rinse aid. - Top up the salt compartment with salt. - Adjust the water softener setting. - Check that the salt compartment lid is properly tightened.
  • G
    Grant BenjaminAug 30, 2025
    How to get rid of bad odour in Hisense HV643D60UK?
    • A
      allenjonesAug 30, 2025
      To eliminate bad odors in your Hisense Dishwasher: - Clean around the seals and in corners with a washing-up brush and low foaming cleaner. - Run a program with a high temperature once or twice a month, or run a self-cleaning program if low temperature programs have been selected for a prolonged period.
  • M
    Michelle RodriguezSep 19, 2025
    What does F41 error mean on Hisense Dishwasher?
    • J
      James WellsSep 22, 2025
      The F41 error on your Hisense Dishwasher indicates a heater fault. Turn off the water tap and remove the plug from the wall socket.
  • J
    James ThompsonNov 20, 2025
    Why is my Hisense HV643D60UK Dishwasher not starting?
    • M
      Michael SmithNov 20, 2025
      Your Hisense Dishwasher might not start because: - The start button may not have been pressed. Press it and the display should start counting down. - The door might not be properly closed. Ensure it is. - The dishwasher may have been opened mid-cycle to add dishes. Simply close the door and wait for the program to continue. - The door lock might not have clicked into place. Check the door lock, and if it hasn't locked, open the door, press and hold the start button until the display counts down, wait for the countdown to end, then close the door ensuring the lock clicks. - The delayed start option might be active. Press and hold the start button for three seconds to cancel it. - The plug may not be properly inserted into the wall socket. Check the connection. - A fuse or circuit breaker m...
  • S
    Shannon KhanSep 9, 2025
    How to fix rattling sound when dishwashing in Hisense Dishwasher?
    • A
      Allison ByrdSep 9, 2025
      If you hear a rattling sound when dishwashing in your Hisense Dishwasher, it may be because the dishes are not correctly placed, or the spray arms are not rotating. Check that the dishes are placed securely and spin the spray arms to make sure they can rotate.
  • D
    David WalkerSep 6, 2025
    Why are there spots left after washing in my Hisense HV643D60UK?
    • J
      Jacqueline RoblesSep 6, 2025
      Spots left after washing in your Hisense Dishwasher may be due to lipstick and tea, which can be difficult to wash off. Use a detergent with a bleaching agent to address this.

Summary

Your Dishwasher Overview

Control Panel Overview

Explains the functions of buttons, display, and indicator lights on the control panel.

Program and Option Selection

Details how to choose and activate washing programs and available options.

Safety Instructions

General Safety Precautions

Essential safety guidelines for operating the dishwasher and handling it safely.

Installation and Preparation

Overflow Guard Function

Explains how the overflow guard operates and the F54 error code.

Storage, Packaging, and Disposal

Guidance on winter storage, packaging materials, and proper disposal procedures.

Before First Use

Water Hardness and Softener Settings

Explains water hardness, how to check it, and set the water softener.

Regeneration Impact on Consumption

Details how water softener regeneration affects energy and water consumption.

Basic Settings

Top Up Rinse Aid

Instructions for refilling the rinse aid compartment for better drying results.

Top Up Salt

Instructions for refilling the salt compartment for water softening.

Greener Dishwashing

Energy and Water Saving Tips

Advice on loading, rinsing, program selection, and water connection for efficiency.

Loading the Dishwasher

Dish Loading Principles

Explains how proper loading impacts washing performance and drying.

Basket and Cutlery Tray Usage

Details on using the upper/lower baskets and the top cutlery tray effectively.

Basket Adjustments

Upper Basket Height Adjustment

How to raise and lower the upper basket to accommodate different dish heights.

Lower Basket Features

Adjustable Plate Supports

How to fold down plate supports for easier loading of pots and bowls.

Using the Dishwasher

Detergent and Compartment Use

Guidance on detergent types, dosage, and compartment usage.

All-in-One Detergent Advice

Advice for using combined detergents and related settings.

Dishwasher Controls and Programs

Control Panel Operation

Details on turning the dishwasher on/off and selecting programs and options.

Program Descriptions

Explains the available wash programs like Eco, Auto, and Intensive.

Program Options and Start;Stop

Program Options Explained

Explains Delayed Start and Speed Wash options for programs.

Start;Stop Operation

How to start, stop, and pause the dishwasher program.

Program Management and Unloading

Stopping, Adding Dishes, and Power Failures

Procedures for interrupting cycles, adding dishes, and handling power outages.

Program Completion and Best Drying

How to know when a program finishes and tips for optimal drying.

Settings Adjustment

Sound and Rinse Aid Settings

Adjusting beep volume and rinse aid dosage levels.

Water Hardness and TAB Settings

Setting water softener and all-in-one detergent options.

Advanced Settings

Auto Dry and Error Readout

Enabling Auto Dry for better drying and viewing error messages.

Factory Reset and Exit

Restoring default settings and exiting the settings menu.

Care and Cleaning

Topping Up Consumables

Instructions for refilling rinse aid and salt compartments.

Cleaning Components

Filter and Spray Arm Cleaning

Steps for cleaning the filter and spray arms to ensure optimal performance.

Exterior and Tub Cleaning

Exterior Cleaning and Self-Clean Program

Cleaning the dishwasher exterior, seals, and running the self-clean cycle.

Troubleshooting: Blockages

Unblocking the Drainage Pump

Steps to clear blockages in the drainage pump to resolve water outlet faults.

Unblocking the Inlet Hose Filter

Steps to clear blockages in the inlet hose filter to resolve water inlet faults.

Troubleshooting: Errors and Basic Issues

Error Messages

Lists common error codes (F10-F67) and their corresponding remedies.

Control Panel and Door Issues

Troubleshooting panel non-responsiveness and door closure problems.

Dishwasher Startup Failures

Steps for when the dishwasher does not start.

Troubleshooting: Wash Performance

Startup and Cleaning Problems

Solutions for when the dishwasher doesn't start or dishes aren't clean.

Troubleshooting: Loading and Spots

Loading and Spotting Issues

Problems arising from incorrect loading and spots on metal or other dishes.

Troubleshooting: Dish Residues and Sounds

Dish Residues and Odors

Solutions for film, spots, detergent residue, water retention, and bad odors.

Rattling and Drainage Issues

Troubleshooting rattling sounds and water remaining in the dishwasher.

Troubleshooting: Drying and Deposits

Grease Deposits and Drying Problems

Solutions for grease buildup and dishes not drying completely.

Installation Guide

Installation Safety and Setup

Crucial safety advice and site preparation for installing the dishwasher.

Installation Connections

Drainage and Water Connections

Instructions for connecting the drainage and water inlet hoses correctly.

Electrical Connection

Information on connecting the dishwasher to the electricity supply.

Service and Support

Technical Data and Energy Labelling

Technical Specifications

Key dimensions, weight, water pressure, and power ratings.

Consumer and Test Institute Information

Sources for product details, energy labelling, and testing information.

Hisense HV643D60UK Specifications

General IconGeneral
Door colorBlack
Water fillCold, Hot
Cord length1.73 m
Control typeTouch
Display typeLED
Product sizeFull size (60 cm)
Tub materialStainless steel
Inlet hose length1.75 m
Number of baskets3 basket(s)
Custom panel-readyYes
Outlet hose length1.5 m
Appliance placementFully built-in
Door panel includedNo
Cutlery compartment typeDrawer
Baskets adjustable placementUpper
Cycle time175 min
Noise level44 dB
Drying systemResidual heat
Delay start (max)24 h
Dishwashing programs60min 65°C, Auto 45-65°C, Delicate 40°C, Eco 50°C, Hygiene 70°C, Intensive 70°C
Number of spray zones5
Number of place settings16 place settings
Number of washing programs6
Number of temperature settings7
Cycle time (quick washing program)15 min
Country of originSlovenia
Package depth665 mm
Package width640 mm
Package height880 mm
Package weight34500 g
Current10 A
Connected load1900 W
Power plug typeType G
AC input voltage220-240 V
AC input frequency50 Hz
Energy efficiency scaleA to G
Power consumption (left-on)0.49 W
Water consumption per cycle11 L
Energy consumption per cycle0.85 kWh
Weight and Dimensions IconWeight and Dimensions
Depth555 mm
Width598 mm
Height816 mm
Weight32500 g
Installation compartment width600 mm
Installation compartment height820 mm
Installation compartment height (max)900 mm
