Hisense LTDN32K560HK3D User Manual

III
Below is the list of video format compatible:
Encapsulation
Video decoding
Audio decoding
Type Resolution (max) Bit rate (max)
．ａｖｉ Ｘｖｉｄ １２８０×７２０ ８Ｍｂｐｓ ＡＣ３， ＭＰＥＧ１（Ｌａｙｅｒ１，２，３）
．ａｖｉ ．ｍｐｇ ．ｔｓ ＭＰＥＧ２ １９２０×１０８０ ２５Ｍｂｐｓ ＡＣ３， ＭＰＥＧ１（Ｌａｙｅｒ１，２，３）
．ｔｓ ．ｍｋｖ ．ａｖｉ Ｈ．２６４ ＨＰ １９２０×１０８０ ２５Ｍｂｐｓ
ＡＣ３， ＡＡＣ，
ＭＰＥＧ１（Ｌａｙｅｒ１，２，３）
．ａｖｉ ．ｍｐｇ ．ｍｏｖ ＭＰＥＧ４ ＡＳＰ １９２０×１０８０ ８Ｍｂｐｓ ＡＣ３， ＭＰＥＧ１（Ｌａｙｅｒ１，２，３）
．ｄａｔ ＭＰＥＧ１ ７２０×５７６ １．５Ｍｂｐｓ ＭＰＥＧ１（Ｌａｙｅｒ１，２，３）
．ｒｍ ．ｒｍｖｂ Ｒｅａｌ ８／９／１０ １２８０×７２０ １．５Ｍｂｐｓ Ｃｏｏｋｅｒ
．ｆｌｖ Ｈ．２６４ ＨＰ ７２０×５７６ １．０Ｍｂｐｓ ＭＰＥＧ１（Ｌａｙｅｒ１，２，３）
Specifications
Model LTDN32K560HK3D LTDN42K560HK3D LTDN47K560HK3D LTDN55K560HK3D
Dimension
(W × H × D) (mm)
Without stand
７３８×４５０×６３ ９７１×５８２×６１ １０８１×６４４．５×６１ １２５５×７４４×６２
７３８×５０１×２００ ９７１×６３９×２５０ １０８１×７０１．５×２５０ １２５５×８０２×３３０
With stand
Weight (kg)
Ｗｉｔｈｏｕｔ ｓｔａｎｄ
８ １３．５ １５．５ ２３
９．３ １６ １８ ２７
Ｗｉｔｈ ｓｔａｎｄ
LCD Panel
Minimum size (Diagonal)
８０ １０６ １１９ １３８
Screen resolution
１９２０×１０８０ １９２０×１０８０ １９２０×１０８０ １９２０×１０８０
Power supply
～ ５０Ｈｚ ２２０Ｖ ～ ５０Ｈｚ ２２０Ｖ ～ ５０Ｈｚ ２２０Ｖ ～ ５０Ｈｚ ２２０Ｖ
Power consumption
５０Ｗ ７５Ｗ １００Ｗ １３０Ｗ
Audio power
６Ｗ＋６Ｗ ８Ｗ＋８Ｗ ８Ｗ＋８Ｗ １０Ｗ＋１０Ｗ
Standard
Ｑ／０２０２ＲＳＲ ５９１－２０１１
Receiving
systems
RF
ＰＡＬ／Ｉ， ＤＴＭＢ
AV
ＰＡＬ， ＮＴＳＣ
Channel range
Ｃ１ ～ Ｃ５７ Ｚ１ ～ Ｚ３５
Environmental conditions
Ｔｅｍｐｅｒａｔｕｒｅ ５℃～ ３５℃ Ｈｕｍｉｄｉｔｙ ２０％ ～ ８０％ＲＨ Ａｔｍｏｓｐｈｅｒｉｃ ｐｒｅｓｓｕｒｅ ８６ｋＰａ ～ １０６ｋＰａ
Antenna input
７５Ω
DTV specication
Ｆｒｅｑｕｅｎｃｙ：４７４ＭＨｚ￣８７４ＭＨｚ Ｔｒａｎｓｍｉｓｓｉｏｎ ｃｈａｎｎｅｌ ｂａｎｄｗｉｄｔ：８ＭＨｚ Ｍｏｄｕｌａｔｉｏｎ：
６４ＱＡＭ，１６ＱＡＭ
，
４ＱＡＭ Ｆｒａｍｅ Ｈｅａｄｅｒ：Ｐｎ９４５ Ｓｙｍｂｏｌ Ｉｎｔｅｒｌｅａｖｉｎｇ：７２０ Ｃｏｄｅ Ｒａｔｅ：０．４， ０．６
Ｖｉｄｅｏ ｄｅｃｏｄｅ Ｆｏｒｍａｔｅ：Ｈ．２６４， ＭＰＥＧ－２ Ａｕｄｉｏ ｄｅｃｏｄｅ Ｆｏｒｍａｔｅ：ＭＰＥＧ－１， ＡＣ－３
Analogue Tune
ＶＨＦ－Ｌ：４８．２５ ￣ １６８．２５ＭＨｚ ＶＨＦ－Ｈ：１７５．２５ ￣ ４６３．２５ＭＨｚ ＵＨＦ：４７１．２５ ￣ ８６３．２５ＭＨｚ
Component Input
４８０ｉ， ４８０ｐ， ５７６ｉ， ５７６ｐ
７２０ｐ／６０Ｈｚ， １０８０ｉ／５０Ｈｚ， １０８０ｉ／６０Ｈｚ， １０８０ｐ／５０Ｈｚ， １０８０ｐ／６０Ｈｚ
The level charactaristics of terminals:
Interface name Interface type Input signal Level Impedance
ＡＶ ｉｎｐｕｔ Ｃｏｍｐｏｓｉｔｅ ｖｉｄｅｏ ｖｉｄｅｏ １．０Ｖｐ－ｐ ７５Ω
Ｃｏｍｐｏｎｅｎｔ ｉｎｐｕｔ
Ａｎａｌｏｇｕｅ
ｃｏｍｐｏｎｅｎｔ ｖｉｄｅｏ
Ｙ １．０Ｖｐ－ｐ ７５Ω
Ｐ
Ｂ
、Ｐ
Ｒ
０．７Ｖｐ－ｐ ７５Ω
ＶＧＡ Ｉｎｐｕｔ ＶＧＡ
Ｒ、Ｇ、Ｂ ０．７Ｖｐ－ｐ ７５Ω
Ｈ
Ｓ
、Ｖ
Ｓ
ＴＴＬ Ｈｉｇｈ ｉｍｐｅｄａｎｃｅ
Ａｕｄｉｏ ｉｎｐｕｔ Ａｎａｌｏｇｕｅ ａｕｄｉｏ Ｌ、Ｒ １Ｖｒｍｓ ＞ １０ ｋΩ
确认此处有无问题
