Selecting a location for the TV
1)Place the TV on the floor or on a sturdy platform in a location where light does not directly hit the screen.
2)Place the TV far enough from the walls to allow proper ventilation. Inadequate ventilation may cause
overheating, which may damage the TV.
NOTE: Please contact local dealer for wall mounting.
Preparation for Using your new TV
Learning about your TV
You can operate your TV by using the buttons on the front panel or the remote control. The terminals on the
back panel provide all the connections you will need to connect other equipment to your TV.
Front Controls
Note: The above figures are for reference only, please refer to the actual units to determine their appearance.
Back Connections
MENU
TV/AV
VOL
CH
AU DIO VIDEO EARPHONE PC AUDIO ANT 75 Y Cb Cr
SCART2 SCART1 INPUT OUTPUT OUT INPUT VIDEO Y Pb Pr PC DVI Rs232 POWER
INPUT
Power Cord
10
11
12
13
14
15
16
17
18
19
20
21
22
PC
POWER
RS 232
PC AUDIO
INPUT
VIDEO
INPUT
EARPHONE
VIDEO
OUT
SCART1
SCART2
AUDIO
INPUT
OUTPUT
Speaker
Connector
Speaker
Connector
23
23
23
23
9
24
