38
6.4.3.2 Removing the condenser fan motor
1. Unplug the appliance.
2. Remove the 6 screws by screwdriver then remove the cover as picture 1.
3. Remove the 1 screws by screwdriver as picture 2.
4. Unplug the terminal as picture 3.
5. Pull out the fan motor as the picture 4, then remove the fan motor as picture 5.
