Other components (42V)
MODEL
NAME
SYMBOL
No.
PARTS No. DESCRIPTION PARTS No. DESCRIPTION PARTS No. DESCRIPTION
#01SA 86994102 SCREW BT BIND HEAD 3X10 86994102 SCREW BT BIND HEAD 3X10 - -
#01SB1 4525404 SCREW M3X10 T - - - -
#01SB2 4525404 SCREW M3X10 T 4525404 SCREW M3X10 T - -
#01 SG35188 CARTON BO
X
SG35473 CARTON BO
X
SG35187 CARTON BO
X
#02 SG35191 TRAY
(
CARTON BOX
)
SG33131 TRAY
(
CARTON BOX
)
SG35191 TRAY
(
CARTON BOX
)
#02SB3 4525401 SCREW M3X8 4525401 SCREW M3X8 - -
#03 SP08506 CUSHION TOP SP08521 TOP CUSHION SP08506 CUSHION TOP
#03SB4 4525404 SCREW M3X10 T 4525404 SCREW M3X10 T - -
#04 SP08512 CUSHION BOTTOM SP08531 BOTTOM CUSHION SP08512 CUSHION BOTTOM
#04SC 4525404 SCREW M3X10 T 4525404 SCREW M3X10 T - -
#05 QL23991 EXTEND LABEL VT QL23992 EXTEND LABEL V - -
#06 - - SG35691 PAD PROTECTOR - -
#08S SG34401 FRONT PAD - - SG34401 FRONT PAD
#300 QJ01192 STAND ASS'Y - - QJ01192 STAND ASS'Y
#641 - - - - 4522885 SCREW 3X8 CE CP-GRIP
#790 MJ03041 BOLT M6X25 WITH WASHER - - MJ03041 BOLT M6X25 WITH WASHER
A11 JP06951 PWB ASS'Y VIDEO JP06951 PWB ASS'Y VIDEO - -
A22 JP06961 PWB ASS'Y TUNER-A - - - -
ETV1 2908801 CONNECTOR 8P - - - -
ETV2 EK01108 WIRE
(
PROCESSED
)
50P - - - -
E02 EV01691 CORD POWER SUPPLY - - EV01691 CORD POWER SUPPLY
E04 EY01951
ADAPTOR RCA-SCART
CONVERSION
EY01951
ADAPTOR RCA-SCART
CONVERSION
- -
N01 QR58551
INSTRUCTION MANUAL
(
EN/CH1/CH2/JP
)
QR58552
INSTRUCTION MANUAL
(
EN/CH1/CH2/JP
)
- -
SPU GM01262
SPEAKER UNIT ASS'Y
DARK SILVER
- - GM01262
SPEAKER UNIT ASS'Y
DARK SILVER
U001 HL02041
REMOTE CONTROL TRANSMITTER
CLE-958
HL01904
REMOTE CONTROL TRANSMITTER
CP-RD4S
- -
42PD5000TA 42PD5000MA 42PD5000VA
