Hitachi 32PD5000 User Manual

5
32PD5000/42PD5000 (PW1)
5
32PD5000/42PD5000 (PW1)
2. Specifications
Panel
Display
dimensions
Approx. 32 inches (716 (H) x 399 (V) mm, diagonal 820mm)
Approx. 42 inches (922 (H) x 522 (V) mm, diagonal 1059mm)
Resolution
852 (H) x 1024 (V) pixels
1024 (H) x 1024 (V) pixels
Net dimensions
(excluding Speakers/Stand)
830 (W) x 506 (H) x 92 (D) mm
1030 (W) x 636 (H) x 91 (D) mm
Net weight
(excluding Speakers/Stand)
24.6kg
34.9kg
Ambient
conditions
Temperature
Operating : 5
C to 35
C, Storage : 0
C to 40
C
Relative humidity
Operating : 20% to 80%, Storage : 20% to 90% (non-condensing)
Power supply
AC100 - 240V, 50/60Hz
Power consumption/at standby
255W / <3W
365W / <3W
Audio output 12W + 12W (6
)
(RGB input)
Input signals
Input terminals
RGB1 DVI input terminal (DVI-D)
RGB1 audio input terminal (3.5mm Stereo Mini Jack)
RGB2 analog RGB input terminal (D-sub 15-pin)
RGB2 audio input terminal (3.5mm Stereo Mini Jack)
Video signals
0.7 V/1.0 Vp-p, analog RGB (Recommended Signal)
480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60
Sync signals
H/V separate, TTL level [2K ]
H/V composite, TTL level [2K
]
Sync on green, 0.3 Vp-p [75 ]
(Video input)
Input signals
Input terminals
AV1: composite video input terminal (RCA)
AV1: Y PB PR video input terminal (RCA)
AV1: L/R audio input terminal (RCA)
AV2: composite video input terminal (RCA)
AV2: Y/G PB/B PR/R video input terminal (RCA)
AV2: L/R audio input terminal (RCA)
AV3: composite video input terminal (RCA)
AV3: S video input terminal (RCA)
AV3: L/R audio input terminal (RCA)
AV4: composite video / S video / RGB / L/R audio input terminal (Scart)
Video signals
AV1: PAL, SECAM, NTSC3.58, NTSC4.43
AV1: 480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60
AV2: PAL, SECAM, NTSC3.58, NTSC4.43
AV2: 480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60, RGB
AV3: PAL, SECAM, NTSC3.58, NTSC4.43
AV4: PAL, SECAM, NTSC3.58, NTSC4.43
AV4: RGB
Video output Signal
OUTPUT (MONITOR): composite video monitor-output terminal (RCA)
OUTPUT (MONITOR): L/R audio monitor- output terminal (RCA)
AV4: composite video / L/R audio output terminal (SCART)
(RF input)
Input signals
Input terminals
ANT : 75
Unbalanced
RF Video System
PAL B, G, H / I / D, K
SECAM B, G / D, K / K1
NTSC-M
Applicable video signals for each input terminal
Terminal RCA/SCART DVI D-sub
Signal CVBS S-video Component RGB PC STB RGB Component
AV1
AV2
AV3
AV4
RGB1
RGB2
( :Available)
