73
32PD5000/42PD5000
POWER UNIT
PANEL Y-SUS PANEL X-SUS
PANEL ABUS-L PANEL ABUS-R
PANEL
LOGIC
(*1)
(*4)
(*3)
CN64
No.1
20P
FFC
CN7
No.3
CN6
CN69
CN68
No.2
NVS7
P#GX00402
CN23
No.4
(To FORMATTER PWB)
CN1
P#2169512
NVS5
To next page
NVS5
P#2169512
Detail of (*1)
1) Release the lock of CN7, and insert No.3 connector in CN7.
2) Lock CN7 to fix the inserted No.3.
3) Insert the other side of No.3 in CN69 completely.
Detail of (*4)
PANEL LOGIC PWB
POWER UNIT
CN69
3
2
1
CN7
No.3
printed letters side
PANEL MODULE
20PFFC
CN1
To PANEL LOGIC PWB
No.4
Detail of (*3)
CONNECTOR WIRE
FERRITE CORE
EFM1
To FORMATTER PWB
13. Wiring diagram
[32PD5000]
