32PD5000/42PD5000 (PW1)

4. Difference table

PWB Ass’y

Other components (32V)

Model 32/42PD5000 32/42PD5000 32/42PD5000

PWB Ass'y

Symbol No. of

Electric Components

TA MA VA

MAIN SW, FILTER, TACT SW,

SP.TERMINAL(L/R),

LED/RECEIVER board

x9xx, xMxx,

x48x, x0xx

AUDIO board

x4xx

JOINT board

xFxx, xHxx

VIDEO board

x2xx, x3xx, x5xx,

x6xx, xRxx

TUNER board

x1xx, xNxx, xTxx

(O: Applied X: Not Applied)

MODEL NAM

SYMBOL No. PARTS No. DESCRIPTION PARTS No. DESCRIPTION

#01SA 86994102 SCREW BT BIND HEAD 3X10 - -

#01SB1 4525404 SCREW M3X10 T - -

#01SB2 4525404 SCREW M3X10 T - -

#02SB3 4525401 SCREW M3X8 - -

#03SB4 4525404 SCREW M3X10 T - -

#04SC 4525404 SCREW M3X10 T - -

#05 QL23991 EXTEND LABEL VT - -

#11 SG35204 CARTON BOX SG35207 CARTON BOX

A11 JP06951 PWB ASS'Y VIDEO - -

A22 JP06961 PWB ASS'Y TUNER-A - -

ETV1 2908801 CONNECTOR 8P - -

ETV2 EK01108 WIRE (PROCESSED) 50P - -

E04 EW08102 CABLE SCART-RCA (3PIN) - -

NVS6 2169511 NOISE FILTER ZCAT1518-0730 - -

NVS9 2169511 NOISE FILTER ZCAT1518-0730 - -

N01 QR58552 INSTRUCTION MANUAL (EN/CH1/CH2/JP) - -

U001 HL02041 REMOTE CONTROL TRANSMITTER CLE-958 - -

32PD5000TA 32PD5000VA
