: should be adjusted
: should be followed previous data
Function
Maximum
Adjustment Items Mode
Value
32" 42"
VIDEO
PWB
TUNER
PWB
PDP
Panel
623 Y OUT LEVEL I (6.0) For Asia Sub 63 13 13
624 Y OUT LEVEL B/G (5.5) For Europe Sub 63 13 13
625 Y OUT LEVEL D/K (6.5) For Europe Sub 63 16 16
626 Y OUT LEVEL I (6.0) For Europe Sub 63 20 20
627 Y OUT LEVEL L (6.5) For Europe Sub 63 13 13
628 Y OUT LEVEL L' (6.1) For Europe Sub 63 13 13
629 Y OUT LEVEL M (4.5) For US Sub 63 13 13
630 C OUT LEVEL M (4.5) For Asia Sub 63 13 13
631 C OUT LEVEL B/G (5.5) For Asia Sub 63 13 13
632 C OUT LEVEL D/K (6.5) For Asia Sub 63 13 13
633 C OUT LEVEL I (6.0) For Asia Sub 63 13 13
634 C OUT LEVEL B/G (5.5) For Europe Sub 63 13 13
635 C OUT LEVEL D/K (6.5) For Europe Sub 63 13 13
636 C OUT LEVEL I (6.0) For Europe Sub 63 13 13
637 C OUT LEVEL L (6.5) For Europe Sub 63 13 13
638 C OUT LEVEL L' (6.1) For Europe Sub 63 13 13
639 C OUT LEVEL M (4.5) For US Sub 63 13 13
640 Contrast Center (CM) DVI-PC 254 128 128
641 Contrast Center (CM) DVI-STB (With Setup) 254 149 149
642 Contrast Center (CM) DVI-STB (Without Setup) 254 128 128
643 Contrast Center (CM) DSUB-RGB 254 128 128
644 Contrast Center (CM) Expand DSUB-RGB (Reserved) 254 128 128
645 Contrast Center (CM) DSUB-COMP 254 137 137
646 Brightness Center (CM) DVI-PC 254 128 128
647 Brightness Center (CM) DVI-STB 254 128 128
648 Brightness Center (CM) DSUB-RGB 254 128 128
649 Brightness Center (CM) Expand DSUB-RGB (Reserved) 254 128 128
650 Brightness Center Offset DSUB-COMP 254 127 127
651 Color Center (CM) DVI-PC 127 77 77
652 Color Center (CM) DVI-STB (480i/576i/480p/576p) 127 77 77
653 Color Center (CM) DVI-STB (720p-60/1080i-60/1080i-50 127 77 77
654 Color Center (CM) DVI-STB (VGA) 127 77 77
655 Color Center (CM) DSUB-RGB 127 77 77
656 Tint Center (CM) DVI-PC 254 128 128
657 Tint Center (CM) DVI-STB (480i/576i/480p/576p) 254 128 128
658 Tint Center (CM) DVI-STB (720p-60/1080i-60/1080i-50 254 128 128
659 Tint Center (CM) DVI-STB (VGA) 254 128 128
660 Tint Center (CM) DSUB-RGB 254 128 128
661 Center of Sharpness (HV Enhance Gain for Y) DVI-STB (480i/576i) 31 3 3
662 Center of Sharpness (HV Enhance Gain for Y) DVI-STB (480p/576p) 31 2 2
663 Center of Sharpness (HV Enhance Gain for Y) DVI-STB (720p-60) 31 2 2
664 Center of Sharpness (HV Enhance Gain for Y) DVI-STB (1080i-60/1080i-50) 31 2 2
665 Center of Sharpness (HV Enhance Gain for Y) DVI-STB (VGA) 31 2 2
666 DVI-STB Setup 0:None VGA/Others Yes, 1:All none 2:All have DVI-STB mode 2 0 0
667 HSYNC De-Jitter 0:Low
(Disabled), 1:(High (Enabled) DVI-PC 1 0 0
668 HSYNC De-Jitter 0:Low (Disabled), 1:(High (Enabled) DVI-STB 1 0 0
669 HSYNC De-Jitter 0:Low
(Disabled), 1:(High (Enabled) AVC 1 0 0
670 Horizontal Clip Offset Level for Y/G AS[YHECLPL3
_
P0] NT2
4/PAL2 4 15 - 10
671 EU[YHECLPL3
_
E
_
P0] NT2
4/PAL2 4 15 - 10
672 Horizontal Clip Offset Level for Y/G AS[YHCLPL3
_
P1] NT2
4/PAL2 4 15 2 -
673 EU[YHECLPL3
_
E
_
P1] NT2
4/PAL2 4 15 5 -
674 Y
_
DL (4.5MHz) For US Main 10 7 7
675 Y
_
DL (4.6MHz) For US Sub 10 7 7
676 Y
_
DL (5.5MHz PAL/NTSC4.43) For Europe Main 10 4 4
677 Y
_
DL (5.5MHz SECAM) For Europe Main 10 1 1
678 Y
_
DL (6.0PAL/NTSC4.43) For Europe Main 10 8 8
679 Y
_
DL (6.0SECAM) For Europe Main 10 5 5
680 Y
_
DL (5.5MHz PAL/NTSC4.43) For Europe Sub 10 2 2
681 Y
_
DL (5.5MHz SECAM) For Europe Sub 10 0 0
682 Y
_
DL (6.0PAL/NTSC4.43) For Europe Sub 10 4 4
683 Y
_
DL (6.0SECAM) For Europe Sub 10 0 0
684 Y
_
DL (6.5MHz PAL/NTSC4.43) For Europe Main 10 5 5
685 Y
_
DL (6.5MHz SECAM) For Europe Main 10 5 5
686 Y
_
DL (6.5MHz PAL/NTSC4.43) For Europe Sub 10 2 2
687 Y
_
DL (6.5MHz SECAM) For Europe Sub 10 0 0
688 Center of Sharpness (HV Enhancer Gain for Y) For Asia/US TV 31 19 19
689 Center of Sharpness (HV Enhancer Gain for Y) For Asia/US VIDEO 31 24 24
690 Center of Sharpness (HV Enhancer Gain for Y) For Asia/US HD5/HD6 31 11 11
691 Center of Sharpness (HV Enhancer Gain for Y) For Asia/US HD1/HD4/HD7/HD8 31 7 7
692 Center of Sharpness (HV Enhancer Gain for Y) For Asia/US HD2/HD3/HD9/HD10 31 15 15
693 Center of Sharpness (HV Enhancer Gain for Y) For Asia/US NT2/NT3/PAL2/PAL3/NT4/PAL4 31 9 9
694 Center of Sharpness (HV Enhancer Gain for Y) For Asia/US TEXT(2 picture) 31 15 15
695 Contrast mode SW (TV-Dynamic) 0:Dynamic 1:Dynamic+Auto TV 1 0 0
696
V detection(FORMATTER PWB)
0:out of range 128:NO V (or out of spec.) 255:interrupt
50/60Hz 255
697
H detection(FORMATTER PWB)
0:out of range 128:NO H (or out of spec.) 255:interrupt
15/28/31/33/45kHz 255
698 V detection(VIDEO PWB) 0:out of range 128:NO V 255
:interrupt 50/60Hz 255
699 H detection(VIDEO PWB) 0:out of range 128:NO H 255
:interrupt 15/28/31/33/45kHz 255
700 RGB Amp.Gain Adjustment (FLAON) Main - - -
701 RGB Amp.Gain Adjustment Sub - - -
702 Automatic White Peak Adj. (Single Picture) Single Picture mode - - -
703 Automatic White Peak Adj. (Multi Picture) Multi Picture mode - - -
704 EEPROM Initialize (0:No, 1:Yes) 1 0 0
705 Adjustment Menu of FC4 - - -
Defaul
t Changed Component
ADJ.
No.
FORMATTER
PWB
To Next Page
