– 27 –
English
PARTS LIST
10” (255mm) STATIONARY TABLE SAW MODEL NO. C10FL
PARTS LIST FOR SCHEMATIC Always order by I.D. Number
Parts No. I.D. Description Size QTY Parts No. I.D. Description Size QTY
726436 09HZ SPINDLE PULLEY 2 726690 237L LOCK HANDLE 1
726437 09JK HEX WRENCH 1 726691 237N CENTER SHAFT 1
726454 0BAC SET NUT 1 726692 237P HEIGHT REGULATER BOLT 1
726455 0BAE ARBOR COLLAR 1 726693 237Q CENTER SHAFT 1
726465 0DMP SPECIAL BOLT L=122 1 726694 237T SET PLATE 2
726466 0GD0 BLADE 1 726695 237U COVER 1
726469 0HVX BALL BEARING 2 726696 237V DUST GUARD 1
726477 0J4E FLAT WASHER φ6*13-1 2 726697 237W GUIDE BLOCK 1
726481 0J4N FLAT WASHER φ16*30-3 3 726698 237X SPONGE 2
325963 0J4R FLAT WASHER φ10*20-3 4 726699 237Y WHEEL 1
726485 0J6T FLAT WASHER 3/16*3/4-1/16 4 726700 237Z SET PLATE 1
726491 0J78 FLAT WASHER 1/4*1/2-3/32 2 726701 238D RETAINING CLIP 1
326109 0J85 FLAT WASHER 5/16*5/8-1/16 4 726702 238G LOCATION SEAT 2
326625 0J8K FLAT WASHER 1/4*3/4-1/16 1 726705 238K ARM BRACKET 2
326207 0J9L SPRING WASHER φ7/16 4 726707 238M WASHER 1
726502 0JAF EXTERNAL TOOTH LOCK WASHER φ5 4 726710 238R COLLAR 1
726506 0JC9 SPRING PIN 1 726711 238S POINTER 1
726508 0JCH SPRING PIN 1 726712 238T ROLLING WHEEL 2
726517 0JG5 PARALLEL KEY 2 726713 238V WORM 1
726519 0JH7 V-BELT 1 726714 239F RAIL 2
726522 0JP3 HEX. HD. BOLT M8*1.25-12 2 726715 239G LINK PLATE 1
726527 0JPU HEX. HD. BOLT M8*1.25-20 4 726716 239H SIDE COVER(LEFT) 1
726532 0JV3 HEX. SOC. HD. CAP BOLT M10*1.5-20 2 726717 239J SIDE COVER(RIGHT) 1
726533 0JV5 HEX. SOC. HD. CAP BOLT M10*1.5-35 4 726718 239K RAIL (LEFT) 1
726534 0JX7 HEX. SOC. SET SCREW M6*1.0-6 4 726719 239L LINK PLATE(BACK) 1
726537 0JZ4 HEX. SOC. SET SCREW M6*1.0-8 2 726720 239M SIDE COVER(LEFT) 1
726530 0K05 HEX. SOC. TRUSS HD. SCREW M8*1.25-20 8 726721 239N SIDE COVER(RIGHT) 1
726531 0K0T HEX. HD. SCREW AND WASHER M8*1.25-20 4 726723 23B9 RAIL (RIGHT) 1
726533 0K10 HEX. HD. SCREW AND WASHER M8*1.25-30 1 726724 23BA SCREW M6*1.0 2
726535 0K17 HEX. HD. SCREW AND WASHER M8*1.25-20 1 726725 23C4 FLAT WASHER T=0.2MM 3
726536 0K19 HEX. HD. SCREW AND WASHER M10*1.5-25 6 726726 23C5 SHAFT 1
726540 0K2C HEX. SOCKET HD. CAP SCREW M8*1.25-16 6 726727 23C6 TORSION SPRING 1
726545 0K3X CR. RE. PAN HD. SCREW & WASHER M5*0.8-14 6 726728 23CA LOCKING ROD 1
325967 0K5T CR. RE. COUNT HD. SCREW M5*0.8-10 4 726729 23CN HEX. SOC. HD. CAP SCREW M6*1.0-40 4
726551 0K61 CR. RE. COUNT HD. SCREW M5*0.8-12 1 726731 23KE HEX. NUT M16*1.5,T=7 1
726555 0K7F CR. RE. ROUND WASHER HD. SCREW M5*0.8-8 4 726732 23KS BALL BEARING 2
726556 0K7G CR. RE. ROUND WASHER HD. SCREW M5*0.8-12 4 726353 2552 HANDLE 1
726565 0K9P CR. RE. TRUSS HD. TAPPING SCREW M6*14-12 13 726735 253M RETAINING CLIP 1
726569 0KA0 CR. RE. PAN HD. TAPPING SCREW M5*12-20 2 726736 253T DUST PLATE 1
726577 0KCX CR. RE. PAN HD PLAIN WASHER TAPPING SCREW M5*0.8-10 4 726737 255V WASHER T=3mm 1
726587 0KFG CR. RE. PAN HD. SCREW M5*0.8-12 4 726748 26MP REAR BRACKET 2
726592 0KK9 SLOTTED PAN HD. SCREW M6*1.-20 2 726749 26PT COMPRESSION SPRING 1
726595 0KL1 CR. RE. PAN HD. ROUND NECK SCREW M6*1.0-12 2 726772 27G2 INSERT ASS’Y 1
726597 0KMS HEX. NUT M6*1.0 T=5 2 726774 27G7 INSERT ASS’Y(DADO) 1
726598 0KMT HEX. NUT M8*1.25 T=5 2 726775 27GA HANDLE 2
726599 0KMU HEX. NUT M10*1.5 T=8 1 726781 27YV HEX. SOC. HD. CAP BOLT M10*1.5-55 1
726601 0KMW HEX. NUT M10*1.5 T=4 1 726788 28DX WORM 1
726603 0KMY HEX. NUT M8*1.25 T=6.5 2 726789 28DY BEVEL GEAR 2
726604 0KN3 HEX. NUT M16*1.5 T=10 1 326626 28DZ SLIDER 2
726606 0KNV HEX. NUT 5/8*18UNF T=8 2 326627 28L0 CLAMP HANDLE 1
726611 0KQF CROWN NUT M8*1.25 T=18 2 726806 28MS BLADE GUARD ASS’Y 1
726614 0KQP SQUARE NUT M8*1.25 T=6.5 6 726807 28MY RIP FENCE ASS’Y 1
726615 0KQW NUT CHUCK M5*0.8 T=5 2 726808 28N0 MITER GAUGE ASS’Y 1
726616 0KQX NUT CHUCK M6*1.0 T=6 2 726818 28RA SWITCH BOX COVER 1
726618 0KR1 NUT CHUCK M16*2.0 T=16 3 325772 28V2 HEX WASHER HD BOLT M6*1.0-16 2
326427 0KTD STRAIN RELIEF 3 726849 28WQ WHEEL CAUTION STICKER 1
326428 0KVQ LEAD WIRE ASS’Y 1 726850 28WR WHEEL CAUTION STICKER 1
726633 0LMK LOCKING CABLE TIE 5 726851 28WS CAUTION LABEL 1
326429 0LSZ CIRCUIT BREAKER SWITCH 1 726855 28WW STICKER LABEL 1
726639 0QGR COMPRESSION SPRING 1 726863 28Z5 ANCHOR BLOCK 2
726640 0R25 COLLAR 1 726864 28Z7 CR. RE. COUNT HD. TAPPING SCREW M4*16-20 2
326430 0STF PARRLE RING ASS’Y 1 726873 293H PUSH BLOCK 1
726654 145M SPRING PIN 2 726355 29E2 ROCKER SWITCH 1
726655 151G O-RING ROD 2 726309 29N3 FLAT WASHER T=0.5MM 2
726656 20LW CR. RE. PAN HD. SCREW & WASHER M5*0.8-16 2 325773 29R2 WARNING LABEL 2
726666 216F SWITCH KEY 1 326191 2FGQ TILTING SCALE 1
726683 22VD PARALLEL PIN 1 326431 2GDS BODY SHELL ASS’Y 1
726684 22VF SLEEVE 1 326432 2GGG MOTOR 1
726686 22VT EXTENTION WING 2 326433 2GGU BODY SHELL ASS’Y 1
726346 2372 TABLE 1 326434 2GGW SWITCH BOX 1
726347 2374 BODY 1 326435 2GGX POWER CABLE 1
726348 2376 HEIGHT LEVER SEAT 1 326436 2GH2 SWITCH MOUNTING 1
726349 2378 CUTTER SHAFT 1 326545 2H0Z RETAINING CLIP 1
726350 2389 WHEEL 1 726870 2H79 BODY SHELL ASS’Y 1
726351 2390 COMPRESSION SPRING 1 326628 2HCC SCALE(LEFT) 1
726687 237E BODY SHELL 1 326629 2HCD LABEL 1
726688 237F BEVEL GEAR 1 326630 2HJ5 SCALE(RIGHT) 1
726689 237G REINFORCE PLATE 1 326631 2HJQ LABEL 1
