Hitachi C 10FL - Unpacking and Checking Contents; Carton Contents

– 8 –
English
If any part is missing or damaged, do not attempt
to assemble the table saw, plug in the power cord,
or turn the switch ON until the missing or damaged
part is obtained and is installed correctly.
STAND
NOTE: To make assembly easier, keep contents of box
together. Apply a coat of automobile wax to the table.
Wipe all parts thoroughly with a clean dry cloth. This will
reduce friction when pushing the workpiece.
V Top leg bracket 1
W Bottom leg bracket 1
X Leg 4
Y Leg front bracket 1
Z R & L leg bracket 1 each
AA Foot and hardware 1 set
BB Storage bracket & foot hardware 1 set
CC Caster assemblies A 2
DD Caster assemblies B 2
EE Stand & caster mounting hardware 36
UNPACKING AND CHECKING CONTENTS
Separate all parts from packing materials. Check each
part with the illustration on the next page and the “Table
of Loose Parts” to make certain all items are accounted
for, before discarding any packing material.
TABLE OF LOOSE PARTS
ITEM DESCRIPTION QUANTITY
A
Table saw assembly 1
B
Table extension wing 2
C
Rear table extension rail 2
D
Front table extension rail 2
E
Rail cover 6
F Blade guard and splitter assembly 1
G
Adhesive washer 5
H
Rip fence 1
I
Miter gauge 1
J
Dust chute 1
K
Blade wrench 1
L
Push stick 1
M
Dodo table insert 1
N
Blade 1
O
Handwheel handle & nuts 1 each
P
Handwheel and handle 1
Q
Table extension hardware
Square nut 6
Hex hd. bolt 2
Hex hd. bolt 4
Hex. socket hd.cap bolt 6
Hex hd. bolt & washer 6
CARTON CONTENTS
WARNING
