Hitachi C 10FR

10" JOB SITE TABLE SAW MODEL NO. C10FR
Always order by I.D. Number.
PARTS LIST FOR SCHEMATIC A
HKU#
I.D. Description Size Qty
HKU#
I.D. Descript ion Size Qty
HKU#
I.D. Descript ion Size Qty
726345
2178
EXTENTION WING (RIGHT)
1
726501
0JAE
EXTERNAL TOOTH LOCK WASHER
2
726625
0KSW
STRAIN RELIEF
1
726354
2771
ANGLE ROD
1
726502
0JAF
EXTERNAL TOOTH LOCK WASHER
1
726628
0KWZ
LEAD WIRE ASS'Y
1
726434
08VH
CLAMP-CORD
1
726503
0JC9
SPRING PIN
1
726632
0LMG
LOCKING CABLE TIE
1
726437
09JK
WRENCH HEX.
1
726507
0JCA
SPRING PIN
2
726635
0LSL
CIRCUIT BREAKER SWITCH
1
0B22
HEIGHT REGULATING BOLT
1
726507
0JCR
SPRING PIN
1
726644
0T00
SLIDING BASE ASS'Y
2
726438
0B23
SADDLE
1
726510
0JED
C-RING
A-16
1
726648
10GN
UPER TUBE
1
726439
0B24
SPRING
1
726513
0JEY
E-RING
E-9
1
726649
10GP
UPER TUBE
1
726440
0B27
POINTER BRACKET
1
726515
0JPB
HEX. HD. BOLT
M5*0.8-20
1
726657
20WQ
HEX. HD. BOLT
M6*1.0-50
1
726441
0B2B
NEEDLE POINTER
1
726534
0JX7
HEX. SOC. SET SCREW
M6*1.0-6
2
726666
216F
SWITCH KEY
1
726442
0B2E
SWITCH BOX
1
726535
0JXL
HEX. SOC. SET SCREW
M10*1.5-12
1
726695
237U
COVER
1
726443
0B3H
INSERT
1
726532
0K0Z
HEX. HD. SCREW AND WASHER
M8*1.25-16
4
726711
238S
POINTER
1
726444
0B3R
WRENCH
1
726534
0K16
HEX. HD. SCREW AND WASHER
M8*1.25-16
1
726759
275D
EXTENTION WING
1
726445
0B84
WASHER
1
726538
0K25
HEX.SOCKET HD.CAP SCREWS
M5*0.8-20
1
726760
275E
UPER TUBE
2
0B97
MOTOR BRACKET
1
726543
0K3G
CR.RE. PAN HD. SCREW & WASHER
M5*0.8-12
1
726761
275F
LOCATION SEAT
2
726446
0B99
SPACER
1
726549
0K57
CR. RE. COUNT HD. SCREW
M5*0.8-16
1
726762
275R
LOCATION SEAT
1
726447
0B9C
PLUNGER HOUSING
1
726557
0K7K
CR. RE. ROUND WASHER HD. SCREW
M6*1.0-12
2
726763
275U
SPACER
1
726448
0B9P
CLAMP
2
726561
0K8C
CR. RE.COUNT HD. TAPPING SCREW
M4*18-10
4
726778
27QV
PARTS BOX CARTON
1
0B9S
BRACKET
1
726562
0K8D
CR. RE.COUNT HD. TAPPING SCREW
M4*18-16
2
726782
287H
RETAINING CLIP
1
726449
0B9W
BRACKET
1
726566
0K9T
HEX. HD. TAPPING SCREW
M5*16-16
6
726786
28CK
POWER CABLE ASS'Y
1
726450
0BA4
SPACER
1
726567
0K9U
HEX. HD. TAPPING SCREW
M5*16-25
8
726790
28FK
TABLE
1
726451
0BA9
SPACER
2
726570
0KA4
CR.RE. PAN HD. TAPPING SCREW
M4*16-16
2
726796
28KX
BODY SHELL
1
726452
0BAA
CLAMP
1
726572
0KAP
CR.RE. PAN HD. TAPPING SCREW
M5*0.8-10
1
726799
28L9
LOCK KNOB
1
726453
0BAB
SHIM
1
726574
0KC8
CR. RE. TRUSS HD. TAPPING SCREW
M4*16-16
2
726802
28MC
PARALLEL BRACKET ASS'Y
1
726454
0BAC
SET NUT
1
726575
0KCA
CR. RE. TRUSS HD. TAPPING SCREW
M5*12-12
2
726803
28MD
MITER GAUGE ASS'Y
1
726455
0BAE
ARBOR COLLAR
1
726576
0KCH
CR.RE. PAN HEAD TAPPING &
WASHER SCREW
M5*0.8-12
2
726804
28MG
HAND WHEEL ASS'Y
1
726456
0BAT
NUT
1
726577
0KCX
CROSS-RECESSED PAN HD PLAIN
WASHER TAPPING SCREW
M5*0.8-10
4
726805
28MH
HAND WHEEL ASS'Y
1
726457
0BAU
SUPPORTING PLATE
1
726577
0KCX
CR. PAN HD. PLAIN WASHER TAPPING
SCREW
M5*0.8-10
2
726809
28N2
BATTERY ASSEMBLY
1
726458
0BAX
STIFFENER
1
726578
0KCY
CROSS-RECESSED PAN HD PLAIN
WASHER TAPPING SCREW
M5*0.8-12
4
726811
28P2
ROCKER SWITCH
1
726459
0BAY
SCREW BAR
1
726581
0KDR
CR. RE. PAN HD. SCREW
M5*0.8-10
1
726812
28PA
KNOB
1
726460
0BAZ
BEARING SEAT
1
726582
0KDU
CR. RE. PAN HD. SCREW
M6*1.0-12
2
726835
28W3
LABEL
1
726461
0BB1
SHAFT
1
726585
0KF6
CR. RE. PAN HD. SCREW
M4*0.7-8
2
726836
28W4
STICKER
1
726462
0BB2
PARRLE RING
1
726587
0KFG
CR. RE. PAN HD. SCREW
M5*0.8-12
2
726837
28W6
STICKER
1
726463
0BC2
LOCATION SEAT
2
726588
0KHZ
CAP HD. SQ.NECK BOLT
M6*1.0-12
2
726838
28W7
CAUTION LABEL
1
0GD0
BLADE
1
726589
0KJ4
CAP HD. SQ.NECK BOLT
M6*1.0-35
1
726839
28W8
LABEL
1
726476
0J3U
WRENCH HEX.
1
726590
0KJ5
CAP HD. SQ.NECK BOLT
M6X1.0-80
1
726840
28W9
SCALE
1
726479
0J4H
FLAT WASHER
φ
10*30-0.2
2
726596
0KMR
HEX. NUT
M5*0.8 T=4
1
726841
28WA
CAUTION LABEL
1
726483
0J5L
FLAT WASHER
φ
5*10-0.3
10
726597
0KMS
HEX. NUT
M6*1.0 T=5
1
726842
28WB
WARNING LABEL
1
726485
0J6T
FLAT WASHER
3/16*3/4-1/16
4
726600
0KMV
HEX. NUT
M10*1.5 T=8
1
726843
28WC
WARNING LABEL
1
726486
0J6U
FLAT WASHER
3/16*1/2-3/64
1
726601
0KMW
HEX. NUT
M10*1.5 T=4
1
726844
28WD
CAUTION LABEL
1
726487
0J6V
FLAT WASHER
3/16*3/8-0.022
9
726603
0KMY
HEX. NUT
M8*1.25
，
T=6.5
1
726845
28WE
SCALE
1
726488
0J70
FLAT WASHER
1/4*3/4-7/64
1
726605
0KND
HEX. NUT
M5*0.8 T=4
2
726846
28WF
SCALE
1
726490
0J76
FLAT WASHER
1/4*3/4-1/16
2
726612
0KQJ
CROWN NUT
M8*1.25 T=12.5
2
726847
28WG
WARNING LABEL
1
726494
0J80
FLAT WASHER
5/32*13/32-
3/64
2
726615
0KQW
NUT CHUCK
M5*0.8 T=5
1
726848
28WL
WARNING LABEL
1
726495
0J8D
FLAT WASHER
3/8*3/4-5/64
2
726615
0KQW
NUT CHUCK
M5*0.8 T=5
1
726861
28X4
BLADE GUARD ASS'Y
1
726497
0J95
SPRING WASHER
1
726622
0KRX
HEXAGON NUT AND FLAT WASHER
M6*1.0
3
726867
290T
BLADE GUARD ASS’Y
1
726500
0JAA
WASHER
1
PARTS LIST
— 67 —
