Cutting accuracy:
[ A direction ]
[ B direction ]
Note: In the case of bevel cutting, there will be uneven
edges of the cut surface if the surface of workpiece is
rough. Check roughness of workpiece. This is
significant especially for the surfaces of workpiece cut
with a band saw.
Fig. 84
Square
Angle gauge
30 mm
45˚
240 mm
(8-7/16")
Wood test piece
Wood test piece
Square
Square
Fence mounting surface
Fence mounting surface
Cutting surface
Workpiece
Uneven
edges
Angle
Accuracy
0˚
45˚
Bevel surface
0˚
A
B
δ (mm)
Fig. 83
δ
δ
0.06
0.5
0.085
0.5
δ
