47
SCREEN menu
Item Description
SOURCE NAME
Each input port for this projector can have a name applied to it.
(1) Use the ▲/▼ buttons on the SCREEN menu to select SOURCE
NAME and press the ► or ENTER button.
The SOURCE NAME menu will be displayed.
(2) Use the ▲/▼ buttons on the SOURCE
NAME menu to select the port to be
named and press the ► button. The
SOURCE NAME dialog will be displayed.
Right side of the menu is blank until a
name is specified.
(3) Select an icon you'd like to assign to the
port in the SOURCE NAME dialog. The
name assigned to the port will also be
automatically switched according to your
icon selection. Press the ► or ENTER
button to determine your icon selection.
(4) Select a number you'd like to assign to
the port along with the icon. You can
select the number either from blank
(no number assigned), 1, 2, 3, or 4.
(5) If you'd like to modify the name assigned
to the port, select CUSTOM NAME and
press the ► button.
(continued on next page)
