Hitachi CP-X608 User Manual

6
Connection to the ports (continued)
S
LAN
RJ-45 jack
Pin Signal Pin Signal Pin Signal
1 TX+ 4 - 7 -
2 TX- 5 - 8 -
3 RX+ 6 RX-
87654
3
21
VIDEO
CONTROL
AUDIO IN 1
AUDIO IN 2
REMOTE
CONTROL
S-VIDEO
AUDIO
OUT
RL RL
AUDIO IN 3 AUDIO IN 4
RGB
OUT
RGB1 RGB2 M1-D
CB/PB
Y
C
R/PR
LAN
AUX I/O
DC 5V 0.5A
SD
C
AR
D
T
S
U
T
AUX I/O
USB A type jack
4
3
2 1
8 7 6 5 4 3 2 1 9
U
SD card slot
SD card slot
Pin Signal
1 +5V
2 - Data
3 + Data
4 Gtound
Pin Signal Pin Signal Pin Signal
1 CD/DAT 3 4 VDD 7 DAT 0
2 CMD 5 CLK 8 DAT 1
3 VSS 6 VSS 9 DAT 2
