7
Installation
Attaching the stand (DF4000DV)
Step 1: Place a soft cushioned material
on top of a flat surface to prevent
damaging the screen panel. Then
place the TV monitor flat on top,
with the screen side facing down,
as illustrated in Fig. 3, right.
Step 2: Align the stand with the neck of
the TV, as illustrated in Fig. 4,
right.
Step 3: Tighten the screws (supplied) with
a screwdriver to affix the stand to
the panel.
Fig. 3
Fig. 4
IMPORTANT!
sMake sure the TV set is unplugged from the power supply before
installing or removing the stand.
sThe TV panel may be awkward to install on your own. We recommend
you ask someone to help with installation and/or removal of the stand.
Your TV is packaged with the stand and the cabinet separated. Before using
the TV, install the stand as described below, or if you want to mount it to a
wall, see page 8 for mounting advice; the wall mount itself is not supplied.
