Controls and Connections
DF2200/DF2200DV/DF2300DV/DF2400/DF2400DV
Main unit controls and sockets
1 LED LCD screen
2 Remote control sensor
3 Power indicator: in standby mode the indicator light will illuminate red;
when switching on the unit the indicator light will illuminate blue.
4 Stand holder
5 VOL +/- button: increase/decrease the volume level or move left/right.
6 CH +/- button: select the next/previous channel or move up/down.
7 MENU button: enter the menu setting page.
8 SOURCE button: select the input source.
9 POWER button: switch the TV on or to standby.
10 Disc slot: insert a disc following the guide on the side of this slot.
11 USB2 port: for multimedia file playback (in DVD mode).
12 SD/MMC/MS Card slot: for multimedia file playback (in DVD mode).
13 : open or close the disc compartment.
14 : start/pause playback.
