Hitachi DS120 G2 - 1.1 Introduction; System Features

ABOUT THE SYSTEM INTRODUCTION
1-1
1.1 Introduction
This document provides an overview of the hardware features of the chassis, troubleshoot-
ing information, and instructions on how to add and replace components of the server.
For the latest version of this manual, see support.HitachiVantara.com
.
System Features
The system comprises a 1U/30.7" long chassis. Major features include:
 Processors (x2): Intel
®
Xeon
®
processor scalable family
 Expansion:
 Option 1
[CPU0]
 (1) OCP 3.0 Mezz x8
 (1) Internal SAS Mezz (Riser Slot5A)
 (1) PCIe HHHL x16 (Riser Slot1A)
[CPU1]
 (1) PCIe HHHL x16 (Riser Slot2A)
 Option 2
[CPU0]
 (1) OCP 3.0 Mezz x8
 (1) Internal Slimline Riser (Riser Slot5B)
 (1) PCIe HHHL x16 (Riser Slot1A)
[CPU1]
 (2) PCIe HHHL x16 (Riser Slot2A)
 Memory: Up to 32 DIMM slots; ECC DDR4 3200 MHz LRDIMM/RDIMM memory
 Up to 8TB (256Gx32) of memory for LRDIMM/RDIMM
 Network*: Dedicated GbE management NIC port from PHY RTL8211E to BMC
CAUTION!
SOME ADD-ON CARDS MIGHT BE HOT AFTER SYSTEM POWER IS OFF. CONTACT SHOULD BE
MADE WITH CARE.
!
