ABOUT THE SYSTEM SYSTEM FEATURES
1-3
Expansion slots
EXPANSION: OPTION1
[CPU0]
(1) OCP 3.0 Mezz x8
(1) Internal SAS Mezz (Riser Slot5A)
(1) PCIe HHHL x16 (Riser Slot1A)
[CPU1]
(1) PCIe HHHL x16 (Riser Slot2A)
EXPANSION: OPTION2
[CPU0]
(1) OCP 3.0 Mezz x8
(1) Internal Slimline Riser (Riser Slot5B)
(1) PCIe HHHL x16 (Riser Slot1A)
[CPU1]
(2) PCIe HHHL x16 (Riser Slot2A)
CAUTION!
SOME ADD-ON CARDS MIGHT BE HOT AFTER SYSTEM POWER IS
OFF. CONTACT SHOULD BE MADE WITH CARE.
Video Integrated Aspeed AST2500 with 8MB video memory
Network options More options refer to the CCL at support.HitachiVantara.com
Front I/O
 Power button/ LED
 Reset button
 ID button/ LED
 System status LED
 HDD LED on HDD tray
 (2) USB 3.0
Rear I/O
 (2) USB 3.0 ports
 (1) VGA port
 (1) Micro USB for BMC console
 (1) ID LED
 (1) PFR LED
 (1) LAN (BMC dedicated)
 (1) microSD port
TPM Yes (optional, SPI mode)
ACPI ACPI compliance, S0, S5 support
Power supply
 (2) 800W/1200W/1600W 86mm Titanium/Platinum redundant PSU, 100-
240VAC 50/60Hz, AC/ HVDC support
 (2) 1200/1600W 86mm Titanium/Platinum redundant PSU, 48V DC
Table 1: System Specifications (Continued)
SPECIFICATIONS DESCRIPTION
!

Hitachi DS120 G2 Specifications

General

Brand	Hitachi
Model	DS120 G2
Category	Computer Hardware
Language	English
