OPERATING THE MACHINE
5-17
AVOID HITTING BLADE WITH FRONT AT-
TACHMENT
When operating the machine with the blade positioned to-
wards the front, the bucket or boom cylinder may come
into contact with the blade if you are not careful. Be sure to
prevent this from happening.
AVOID HITTING BLADE WITH BUCKET
When crowding the arm into a traveling or transporting po-
sition, be careful not to let the bucket hit the blade.
AVOID STRIKING THE BLADE INTO A ROCK
Don’t attempt to strike large rocks with the blade, as doing
so will damage the blade and the blade cylinders, shorten-
ing their operating lives.
M586-05-016
M586-05-017
M586-05-017
M586-05-035
To Next Page
