OPERATING THE MACHINE
5-3
SHIFTING THE CONTROL LEVER CONTROL
PATTERN
The control lever control pattern can be shifted between
the ISO-EXCAVATOR PATTERN and SAE-BACKHOE
PATTERN by selector valve (9). Before shifting the control
lever control pattern, be sure to stop the engine. Rotate
selector valve (9) to the desired control pattern position
using the attached tool.
M586-01-053
M586-01-051
9
9
ISO
SAE
To Next Page
