Electrical specifications
Item Controller Drive tray
Frequency (Hz) 50/60 ±1
Number of phases, cabling Single-phase with protective grounding
Steady-state current 100V/
200V
1
,
2
CBLH: 4.0x2 FMD drive tray: 2.6x2/1.3x2
Current rating of breaker/fuse
(A)
16.0 (each electrical)
Heat value (normal) (kJ/h)
2810 or less FMD drive tray: 1520 or less
FMD drive tray: 1520 or less
Steady-state power (VA/W)
3
CBLH: 1600/1560 or less FMD drive tray: 520/490 or less
Power consumption (VA/W)
CBLH: 840/780 or less FMD drive tray: 440/420 or less
Notes:
1. The power current of Nx2 described in this table is required for a single power unit.
2. If one power unit fails, another power unit requires electric current for the two power units.
Therefore, plan the power supply facility so that the current-carrying capacity for one power
unit can provide the total capacity for two power units.
3. This table shows the power requirement (100 V or 200 V) for the maximum configuration .
The actual required power might exceed the value shown in the table when the tolerance is
included.
70 Electrical specifications for VSP F800
Hitachi Virtual Storage Platform F800 Hardware Reference Guide
