Number Item Description
1 STATUS LED Green: Back-end module is in the power-
on state.
Red: Back-end module can be removed
safely.
2 PORT LED Blue: Link status is normal.
3 PATH 0 connector Connect to a drive tray.
4 PATH 1 connector Connects to a drive tray.
Back-end modules
Chapter 2: System controller
Hitachi Virtual Storage Platform G700 Hardware Reference Guide 26
