Chapter 2 System Overview
2-1
Chapter 2 System Overview
This chapter describes the system configuration of the MICRO-EH.
The MICRO-EH is an all-in-one type programmable controller, and has the following system configuration.
Figure 2.1 10-point type system configuration diagram
Figure 2.2 14-point type system configuration diagram
1] Basic unit
1] Basic unit
3] Expansion cable3] Expansion cable3] Expansion cable3] Expansion cable
2] Expansion unit2] Expansion unit2] Expansion unit2] Expansion unit
