Chapter 12 Error Code List and Special Internal Outputs
12-11
No. Name Stored data Description
Setting
condition
Resetting
condition
WRF057
Detailed information
of counter setting
errors
a: Error in pulse frequency total
b: Pulse 4 frequency c: Pulse 3 frequency
d: Pulse 2 frequency e: Pulse 1 frequency
f: Counter 4 preset g: Counter 3 preset
h: Counter 2 preset i: Counter 1 preset
0=Normal, 1=Error
Set by the
system
Cleared by
the system
WRF058
PI/O function
individual setting
request 1 *
a: Output number (during pulse setting)
Off-preset (during counter setting)
b: On-preset (during counter setting)
Frequency (during pulse setting), frequency, on-duty (during
PWM setting)
0=No changes, 1=Change request
Set by user
Cleared by
the system
WRF059
PI/O function
individual setting
request 2 *
a: Output number (during pulse setting)
Off-preset (during counter setting)
b: On-preset (during counter setting)
Frequency (during pulse setting), frequency, on-duty (during
PWM setting)
0=No changes, 1=Change request
Set by user
Cleared by
the system
WRF05A
PI/O function
individual setting
request 3 *
a: Output number (during pulse setting)
Off-preset (during counter setting)
b: On-preset (during counter setting)
Frequency (during pulse setting), frequency, on-duty (during
PWM setting)
0=No changes, 1=Change request
Set by user
Cleared by
the system
WRF05B
PI/O function
individual setting
request 4 *
a: Output number (during pulse setting)
Off-preset (during counter setting)
b: On-preset (during counter setting)
Frequency (during pulse setting), frequency, on-duty (during
PWM setting)
0=No changes, 1=Change request
Set by user
Cleared by
the system
WRF05D
to F06A
Undefined Do not use.
1514 876543210
a
Not used
bcdefgh i
15 2 1 0
Not used
ab
15 2 1 0
Not used
ab
15 2 1 0
Not used
ab
15 2 1 0
Not used
ab
