— 8 —
English
SPECIFICATIONS
Operating pressure 70 – 120 psi (4.9 – 8.3 bar 5 – 8.5 kgf/cm
2
)
Dimensions 21-3/16" × 13-3/8" × 4-1/4"
Length × Height × Width (538 mm × 340 mm × 108 mm)
Weight 8.6 lbs (3.9 kg)
Nail capacity 64 – 70 nails (2 strips)
.088 ft
3
/cycle at 100 psi
Air consumption (2.5 ltr/cycle at 6.9 bar)
(2.5 ltr/cycle at 7 kgf/cm
2
)
Air inlet 3/8 NPT Thread
NAIL SELECTION
WARNING
䢇 Be sure to use only the genuine HITACHI nails for the NR83A2(Y)/NR83A2(S1). The use of any other nails can result in
tool malfunction and/or nail breakdown, leading to serious injuries.
Only nails shown in the Table below can be driven with this Nailer.
ACCESSORIES
WARNING
䢇 Accessories other than those shown below can lead to malfunction and resulting injuries.
STANDARD ACCESSORIES
.113"
(2.9 mm)
.286"
(7 mm)
2" (50 mm)
.131"
(3.3 mm)
3-1/4" (83 mm)
Plastic-collated strip nails Min. Max.
Full-head nails
1 Eye protection ...................................................... 1
1
.3"
(7.6 mm)
