COMPONENT NAMES
Main Unit
① Panel
② Remote Control Receiver
③ Indicating Lamp
④ Speaker
⑤ Desktop Stand
① Handgrips
② Side Input
③ Rear Input
④ Control Panel (see below for details)
⑤ Cable Clampers
Please refer to
14
~
18
for the detailed
information for the connections.
① Main Power Switch (
)
②
Channel UP
③ Channel DOWN
④ Volume UP
⑤ Volume DOWN
⑥ INPUT button
⑦ Sub Power button ( )
To display the menu screen.
Press both VOL
ϵ/϶ buttons at the same time for
more than 1 seconds to display the menu screen.
CH ϳ/ϴ buttons, VOL ϵ/϶ buttons and INPUT (as
ENTER) button can be used to select or enter the
desired setting during the menu screen operations.
Front Panel
⑦
⑤
