S1 series standard inverter
-33-
Chapter 5 Basic operation instructions
5.1 What this chapter contains
This chapter tells users how to use the inverter keypad and the commissioning procedures for
common functions of the inverter.
5.2 Keypad introduction
LED keypad is included in the standard configuration of S1 series inverter. Users can control the
inverter start/stop, read state data and set parameters via keypad.
Fig 5.1 External Keypad (up to 2.2kW)
Fig 5.2 Keypad (4-400kW)
