WIRING ARRANGEMENT
Cleaning and maintenance must be carried out only by qualifi ed service personnel. Before
cleaning, stop operation and switch off the power supply.
!
CAUTION
CAUTION
● Please use ground wiring.
Do not place the ground wiring near water or gas pipes, lightning-conductor, or the ground
wiring of telephone. Improper installation of ground wiring may cause electric shock.
● A circuit breaker should be installed depending on the mounting site of the unit. Without a circuit breaker,
the danger of electric shock exists.
IMPORTANT
The wires in this mains lead are coloured in accordance with the following code:
Green-and-yellow : Earth/Ground
White : Neutral
Black : Line
As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
The wire which is coloured green-and-yellow must be connected to the terminal in the plug which is marked with
the letter E or by the earth symbol
or coloured green or green-and-yellow.
The wire which is coloured white must be connected to the terminal which is marked with the letter N or coloured
black.
The wire which is coloured black must be connected to the terminal which is marked with the letter L or coloured
red.
NOTE
If the supply cord is damaged, it must be replaced with the new cord obtainable at authorized service parts centers.
2. CLEANING OF FRONT PANEL
CAUTION
● Never use hot water (above 40°C), benzine, gasoline, acid, thinner or a
brush, because they will damage the plastic surface and the coating.
Removing the Front Panel Attaching the Front Panel
!
● Remove the front panel and wash with clean water.
Wash it with a soft sponge.
After using mild detergent, wash thoroughly with clean water.
● When front panel is not removed, wipe it with a soft dry cloth.
Wipe the remote controller thoroughly with a soft dry cloth.
● Wipe the water thoroughly.
If water remains at LEDs or signal receiver of indoor unit, it
causes trouble.
Method of removing the front panel.
Be sure to hold the front panel with both hands to detach
and reattach it.
● When the front panel is fully opened with both
hands, push the right arm to the outside to release
it, and while closing the front panel slightly, pull it out
forward.
● Move the projections of the left and right arms
into the Flanges in the unit and securely insert
them into the holes.
