Chapter 1 Overview
1.3 Exterior Views and Names of Parts
The figure below shows an exterior view of the inverter (model SJ700-150LFF2/HFF2 to
SJ700-220LFF2/HFF2).
Digital operator
Spacer cover
Terminal block cover
ALARM lamp
POWER lamp
Front cover
Specification label
Exterior view of shipped inverter
For the wiring of the main circuit and control circuit terminals, open the terminal block cover.
For mounting optional circuit boards, open the front cover.
Position to mount optional board 1
Main circuit terminals
Backing plate
Control circuit terminals
Position to mount optional board 2
Exterior view of inverter with front and terminal block covers removed
1 - 3
