OPERATING THE MACHINE
5-2
Boom-Swing Pedal
Use the boom swing function to efficiently operate the
machinewhenexcavatinggroovesalongroadsidesor
near walls. The boom swing operation is performed using
boom-swingpedal(1)locatedattheoperator’srightfootas
illustrated to the right.
Boom-Swing Operation
1. Turncover(2)forboom-swingpedal(1)forward.
2. Stepontheleftsideofboom-swingpedal(1)toswing
left.Stepontherightsideofpedal(1)toswingright.
3. Turncover(2)backwardoverboom-swingpedal(1)
whenboom-swingoperationisnolongerrequired.
3- SwingLeft
4- SwingRight
3 4
21
UnlockPosition
2
LockPosition
MADB-05-001
MADB-01-062
MADB-00-001
