OPERATOR'S STATION
1-11
Indicators
Overheat Indicator (1)
This indicator warns abnormally increased coolant
temperature.TheredlightcomesONandthebuzzersounds
simultaneously.WhentheredlightcomesONandthe
buzzer sounds, immediately stop the machine operation,
run the engine at slow idle speed and lower the coolant
temperature.
Engine Oil Pressure Indicator (2)
This indicator warns low engine oil pressure. The red light
comesONandthebuzzersoundssimultaneously.Whenthe
redlightcomesONandthebuzzersounds,immediately
stoptheengine,checktheengineoilsystemandtheoil
level.
Alternator Indicator (3)
This indicator warns abnormality of the electric system
whilerunningtheengine.Whenthealternatorvoltagefalls
outofthespecifiedrange,theredlightcomesON.Check
the alternator and the battery system.
Fuel Level Indicator (4)
WhentheremainingfuelindicatorcomesONataflat
ground,theremainingfuellevelwillbeasfollows.Refillfuel
as soon as possible.
Model Fuel Level
ZX30U-5N,35U-5N Approximately9L
ZX50U-5N Approximately11L
ZX60USB-5N Approximately12L
1 2 3 4
MADG-01-090
