Hitachi ZAXIS 35U-5N User Manual

MAINTENANCE
7-54
Drain Fuel Tank Sump
--- As reguired
1. Parkthemachinefollowingthesameproceduresas
describedonpage7-6forpreparationforinspectionand
maintenance.
2. Loosenbolts(2)toremovedrainvalvecover(3)from
right-frontundercover(1).Rotatedrainvalvecover(3)to
openthecheckingport.
3. Placea0.5litersorlargercapacitycontainerunderdrain
valve (4) to collect the drained water.
4. Opendrainvalve(4)todrainwaterand/orsediment.
5. After draining water, securely tighten drain valve (4).
6. Returndrainvalvecover(3)tooriginalpositionand
tighten bolts (2).
1
2
4
3
MADB-07-024
MADB-07-025
