OPERATOR'S STATION

1-96

Right Console / Switches

Fingertip Control Type

1- * Auxiliary Control Lever (Optional)

2- * Bucket Control Lever

3- * Lift Arm Control Lever

4- Forward/Reverse Switch

5- Control Lever Lock Switch

6- Clutch Cut Position Switch

7- Travel Mode Selector

8- Power Mode Switch

9- Forward/Reverse Selector Switch

10- Fan Reverse Rotation Switch

11- Auxiliary

12- Auxiliary

13- Emergency Steering Operation Check Switch

14- Aftertreatment Device Regeneration Switch

15- Auxiliary

16- Auxiliary

17- Ride Control Switch

18- Armrest Adjust Handle

19- Armrest

20- Hold Switch

21- Right Console Slide Lever

22- DSS (Down Shift Switch)

23- Horn Switch

24- Quick Power Switch

NOTE: * The location of control levers may be changed

depending on the specification.

19 18

1 (2)

2 (3)

3 (1)

MNEC-01-041

MNEC-01-042
