6 / 18
6. ORDER INFORMATION
Model Function Configuration Product Code
ARC160D
Hot start arc ignition
self-adaptive arc force
Anti-stick
MMA/Lift-TIG
VRD
Z2A4
ARC200D Z2A5
7. TECHNICAL PARAMETERS
Technical
Parameter
Unit
Model
ARC160D ARC200D
Rated input
voltage
V
AC120V±15%
50/60HZ
AC240V±15%
50/60HZ
AC120V±15%
50/60HZ
AC240V±15%
50/60HZ
Rated input power KVA 5 7.1 6 9.4
Welding current
range
A 20-120 20-160 20-140 20-200
V 20.8-24.8 20.8-26.4 20.8-25.6 20.8-28
Rated duty cycle
①
% 20 20
No-load voltage V 85 85
Overall efficiency % 85 85
Housing
protection grade
IP 21S 21S
Power factor cosφ 0.7 0.7
Insulation grade H H
Standard IEC60974-1
Noise db
＜70
Size
with
handle
②
mm
305* 112* 190 mm 335* 112* 190 mm
Weight kg 3.560 4.220
Applicable
electrode
mm 1.0-3.2 1.0-5.0
“①”- under the environment temperature of 40℃
“②”- Not every piece of machine has the same design. Differences may exist upon customers’ requirements.
