1. Install the Handlebar
1. Rotate the handlebar tube towards the front of the bike and adjust
the tube and fork to be parallel and perpendicular to the frame.
1
2. Use the No. 5 Allen key from
the 16-in-1 tool to tighten the
top cap screw.
3. Use the No. 4 Allen key in the 16-in-1 tool to
tighten the screws "a" and "b" in the picture.
Note: The two screws should be tightened
gradually, do not tighten one first, then tighten the
other one.
2
3
-2-
